VOIP Hardware - VOIP Accessories - Desk Phones :: Polycom - Polycom IP321
Polycom IP321 SoundPoint VoIP Phone - AC Adopter
Overview
Polycom Part Number: 2200-12651-001
The Polycom IP321 is a two-line SIP phone that delivers superb sound quality as well as a wide range of supported business telephony features. The SoundPoint IP 321 phone has a single 10/100 Ethernet port and is designed for common areas, such as lobbies, hallways, and break rooms, as well as various wall-mounted deployments. The SoundPoint IP 331 phone, with its dual-port 10/100 Ethernet switch for LAN and PC connection, presents a cost-effective solution for cubicle workers as well as call center operators who use a “hard” phone in conjunction with a “soft” client running on the PC.
- Excellent Sound Quality
- 2 Lines, Single Ethernet with PoE
- Remote, Zero-Touch Provisioning
Polycom IP321 VoIP Phone Features & Functions:
- Up to 2 lines with up to 2 calls per line
- 3 context-sensitive “soft” keys
- 2 line keys with bi-color (red/green) LED
- 2 feature keys (“Menu” and “Dial”)
- 4-way navigation key cluster with center “Select” key
- 2 volume control keys
- Dedicated hold key
- Dedicated headset key
- Dedicated hands-free speakerphone key
- Dedicated microphone mute key
- Headset Compatibility
- Dedicated 2.5-mm headset port compatible with most monaural mobile phone headsets
- UNIT IS PoE. No Power Supply included
- To buy the addational power clieck here: http://www.IPStore.com/Polycom-24V-Power-Supply-IP321-331-450-550-650-Single/
Features
| Lines Supported | 2 lines |
| Speed Dial Capacity | 2 |
| Type | LCD display - monochrome |
| Display Location | Base |
| Display Information | Date, time |
| Display Resolution | 102 x 33 pixels |
| Connections | 1 x headset jack / sub-mini-phone 2.5 mm |
| Cables Included | Network cable - 10 ft |
| Placing / Mounting | Wall-mountable, table-top |
| Hearing Aid Compatible | Yes |
| Service & Support | 1 year warranty |
| Service & Support Details | Limited warranty - 1 year |
| Main Features | Multiline support, integrated Ethernet switch, Power over Ethernet (PoE) support |
| Voice Codecs | G.729a, G.729ab, G.711u, G.711a |
| IP Address Assignment | DHCP, static |
| Network Protocols | TFTP, HTTP |
| Network Ports Qty | 2 x Ethernet 10Base-T/100Base-TX |
| Voice Features | Comfort noise generation (CNG), voice activity detection (VAD), echo cancellation (ECN) |
| VoIP Protocols | SIP |
| Quality of Service | IEEE 802.1Q (VLAN), Differentiated Services (DiffServ), IEEE 802.1p, Type of Service (ToS) |
| Network Features | Network Address Translation (NAT) |
